Default [UPDATED 30.03.11] HD2 Windows Phone Development

UPDATED 30.03.11

htcrie v.0.7.0.46

+ Added the ability to increase the size of IMGFS partition.
(MaxDataSize: 244 Mb)
+ User Partition not present in ROM more.
(640 Kb+ )
- The command line is not supported by more in the public version.
+ Custom Logo.
Not all images support yet.


---------------------------------------------------------------------------------------------------------------

Now we can:
- change the content of imgfs and use 244 Mb of free space
- edit registry
- create and replace custom Bitmap (first Logo)
- extract all partition(s), file(s), package(s) and s.o.




Thanks a lot to Football and Mag Light for helping me to test this feature,
because I do not have any wp7 device.


1. To extract contetnt of IMGFS/BLDR/SLDR/NK/LOGO use htcRIE_0.7.0.46
Files:
Code:
Select IMGFS -> Select All Items (Click One Item -> Ctrl+A) -> Save selected files
Partition:
Code:
Select IMGFS -> Save selected files
Packages:
Code:
Select IMGFS -> Select SYS/OEM/Packege(s) -> Save selected files

2. To edit default.hv and user.hv use HVEdit_v.2.0.112
You can use drag-and-drop. Create shortcut first.

3. To rebuild IMGFS use imgfsfromdump (or other tool), but don`t forget a new cecompr_nt.dll (with XPH compression type support).
You can use cecompr7_nt.dll from htcRIE_0.7.0.46.zip, but rename to cecompr_nt.dll first.

4. To replace IMGFS use htcRIE_0.7.0.46 again.
Code:
Select IMGFS -> Add File -> Choose a new *.bin file (save command donīt need)
5. To replace custom Bitmap use 24-Bit-Bitmap (480x800)
Code:
Select Logo0 -> Add File -> Choose a new *.bmp file (save command donīt need)

First WP7 Custom ROMs:
HTC Leo - Project "moon light" [WP7] [RUS]
HTC Leo - Project WыньPhone7 [WP7], HTC HD2 / HTC T8585

AnDim
The Following 36 Users Say Thank You to AnDim For This Useful Post: [ Click to Expand ]

arkatis
Old
#2
arkatis's Avatar
Senior Member
Thanks Meter 414
Posts: 1,058
Join Date: Dec 2008
Location: Cyprus-Nicosia
Am i smelling something fresh???
I love XDA. QUIETLY BRILLIANT!

MY HTC HD2 Rom here:
[12/07/2012] Arkat-DoubleSense v.4.0 [Marcs1706 0.2.2] {FASTEST SENSE 2.1 FOR HD2}

MY HTC SENSATION ROM:
Unavailable. (sold device)

I am a flash-a-holic!

HTC DEVICES THAT I OWNED:
3x HTC HD2 Leo and 1 HD2 TMobile US
HTC HD7
HTC SENSATION
HTC DESIRE HD
Wildfire s

Current Devices:
HTC ONE X




The Following User Says Thank You to arkatis For This Useful Post: [ Click to Expand ]

viettho
Old
#3
Member
Thanks Meter 4
Posts: 83
Join Date: May 2007
Location: Garden Grove
something good is coming .... i can feel it
S3

05081983
Old
#4
Member
Thanks Meter 9
Posts: 81
Join Date: Jun 2008
Location: Northridge
What's Coming.................

Krendelrus
Old
#5
Senior Member
Thanks Meter 421
Posts: 602
Join Date: Nov 2010
looking forward to it

Direkts
Old
#6
Junior Member
Thanks Meter 4
Posts: 25
Join Date: Jan 2011
Location: Łódź
Yeah, it will start season for "cooked" rom's? :P

HTC HD2
NDT GINGER MIUI
The Following 2 Users Say Thank You to Direkts For This Useful Post: [ Click to Expand ]

arkatis
Old
#7
arkatis's Avatar
Senior Member
Thanks Meter 414
Posts: 1,058
Join Date: Dec 2008
Location: Cyprus-Nicosia
Quote:
Originally Posted by Direkts View Post
Yeah, it will start season for "cooked" rom's? :P
It was about time!
I love XDA. QUIETLY BRILLIANT!

MY HTC HD2 Rom here:
[12/07/2012] Arkat-DoubleSense v.4.0 [Marcs1706 0.2.2] {FASTEST SENSE 2.1 FOR HD2}

MY HTC SENSATION ROM:
Unavailable. (sold device)

I am a flash-a-holic!

HTC DEVICES THAT I OWNED:
3x HTC HD2 Leo and 1 HD2 TMobile US
HTC HD7
HTC SENSATION
HTC DESIRE HD
Wildfire s

Current Devices:
HTC ONE X





vartp
Old
#8
Member
Thanks Meter 9
Posts: 50
Join Date: Aug 2010
reserved for comment about it

richdmond
Old
#9
richdmond's Avatar
Member
Thanks Meter 0
Posts: 30
Join Date: Aug 2009
Location: Melegnano (MI)
@_@ battery life must be decent please!

Sent from my HTC hd2 miui using XDA App
Android on HD2 pleaseee!!!
Currently Running: ChuckyROM Latest Build

cmoserror1
Old
#10
cmoserror1's Avatar
Junior Member
Thanks Meter 0
Posts: 7
Join Date: Jun 2010
Location: North Monmouth, ME


DONATE TO ME
Oh boy im getting excited
