[RECOVERY] Custom CWM-Based Touch Recovery 5.0.2.7 for HTC Flyer HC [v02][Dt:20/JAN]

Tip us?

DooMLoRD
Old
(Last edited by DooMLoRD; 4th June 2012 at 03:24 PM.)
#1
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
Angry [RECOVERY] Custom CWM-Based Touch Recovery 5.0.2.7 for HTC Flyer HC [v02][Dt:20/JAN]

This is a Custom CWM-Based Recovery 5.0.2.7 for HTC Flyer

Credits and special thanks to Koush and everyone else involved in Cyanogenmod project!






for more screenshots check attachments



[ info ]

This Recovery will reside on the /recovery partition of the device and will give you lots more features than any existing recoveries for this device...



[ credits / special thanks ]
  • Koush - for the brilliant work & coding on CWM recovery
  • Team Revolutionary - for the initial CWM4 recovery... i have used the recovery.fstab and HTC charger from their recovery-ramdisk
  • Napstar - my teammate (Team UtterChaos) for his work on implementing touch based interface
  • sztupy - for his work on SteamMOD recovery (the core touch interface is based on his work)



[ Requirements ]
  • S-OFF device
  • HoneyComb version
  • WiFi Flyer only????
  • CWM4 Recovery (by Team Revolutionary)



[ features ]
  • now featuring Touch based navigation interface!
  • features derived from CWM5
    • ability to backup & restore to/from internal SDCARD
    • ability to flash custom update.zip from internal SDCARD
    • faster .TAR backups (backups created using this new recovery MAY NOT BE COMPATIBLE with older CWM4)
  • my additions
    • changes to graphics (ported some graphics from CWM5.5 ICS edition)
    • revamped layout for recovery menu (to improve navigation) [renamed few options and changed their order]
    • changed "wipe data/factory reset" option to just "factory reset", and detailed the partitions which will be wiped
    • added reboot options
      • reboot into system
      • reboot into recovery
      • reboot into fastboot mode
    • some modification in "Partition SDCard" section:
      • put up a confirmation to warn the user that this option will wipe sdcard
      • added ability to select filesystem when creating new layout
    • add confirmation to "backup" option in Nandroid menu... it used to keep getting pressed by mistake and start making backups immediately... now it will ask u before starting backup
    • removed tons of "NO"s from some menus...


[ WARNING ]


THIS RECOVERY IS STILL IN TESTING... MAKE SURE THAT U HAVE UR COMPLETE DATA BACKED-UP (INCLUDING SDCARD DATA)...

and incase this doest work correctly make sure that u can restore to factory condition...

"Partition SDCard" option in CWM5 WILL WIPE UR EXTERNAL SDCARD!!!

I have only tested it to work on my WIFI Flyer... please check if it works for the 3G version... if 3G version uses a different partition table THEN DO NOT USE IT ON 3G VERSION!





[ how to install this recovery ]
  1. download the recovery package (its an update.zip)
  2. place the downloaded package on external SDCARD
  3. reboot into recovery and flash this package
  4. thats it! new recovery will now be installed


[ how to get back to Team Revolutionary's CWM4 Recovery ]
  1. download the Team Revolutionary's CWM4 Recovery package (its an update.zip)
  2. place the downloaded package on external SDCARD
  3. reboot into recovery and flash this package
  4. thats it! old recovery will now be installed


[ donations ]

if u feel that this work has helped u OR u think that the work i put into making this is worthy of donations, then click on the following link for buying me some coffee/beer/etc

PAYPAL DONATION LINK


[ download links ]



[FLYER][HC] CWM-Based Touch Edition Recovery 5.0.2.7 by DooMLoRD (v02)
MD5HASH: c05da93ec4744eaffcc6f440691c8790


[Flyer][GB] CWM-Based Touch Edition Recovery 5.0.2.7 by DooMLoRD (v02)
MD5HASH: 91bf21aa8ddb4fc8504b8103942c957f


[FLYER] CWM-Based Recovery 5.0.2.7 by DooMLoRD (v01) < OLD NON-TOUCH >
MD5HASH: 68470906ea654d6c9cff88930d5e7480


Team Revolutionary's CWM4 Recovery


KINDLY DO NOT MIRROR MY FILES



please do intensive testing and let me know!





enjoy!!!
Attached Thumbnails
Click image for larger version

Name:	flyer-mycwm-2.jpg
Views:	3692
Size:	16.4 KB
ID:	831362   Click image for larger version

Name:	flyer-mycwm-3.jpg
Views:	1121
Size:	14.3 KB
ID:	831363   Click image for larger version

Name:	flyer-mycwm-4.jpg
Views:	1071
Size:	15.8 KB
ID:	831364   Click image for larger version

Name:	flyer-mycwm-5.jpg
Views:	1053
Size:	13.2 KB
ID:	831365   Click image for larger version

Name:	flyer-mycwm-6.jpg
Views:	2336
Size:	12.4 KB
ID:	831367

The Following 23 Users Say Thank You to DooMLoRD For This Useful Post: [ Click to Expand ]

DooMLoRD
Old
#2
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
reserved for later

DooMLoRD
Old
#3
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
i need people to test this recovery out and give me feedback asap.. because i am working on a TouchEdition recovery which will be based on this...



so do let me know how this works out!
Attached Thumbnails
Click image for larger version

Name:	flyer-mycwm-1.jpg
Views:	18784
Size:	20.6 KB
ID:	831439
The Following User Says Thank You to DooMLoRD For This Useful Post: [ Click to Expand ]

globatron
Old
#4
Recognized Developer
Thanks Meter 2,047
Posts: 1,436
Join Date: Jun 2009
Location: All over the place


DONATE TO ME
DooMLoRD, can you confirm that you have off-mode charging working properly? Having a recovery that doesn't is not a good situation to get into in a device with no removable battery.

DooMLoRD
Old
#5
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
Quote:
Originally Posted by globatron View Post
DooMLoRD, can you confirm that you have off-mode charging working properly? Having a recovery that doesn't is not a good situation to get into in a device with no removable battery.
the necessary files for that are already in place...

may be someone can help test that...

additionally: is the partition layout on GB different? and waht abt the 3G version?

Flyer.michael
Old
(Last edited by Flyer.michael; 27th December 2011 at 08:30 PM.)
#6
Flyer.michael's Avatar
Senior Member
Thanks Meter 43
Posts: 219
Join Date: Jun 2011
Location: Landshut


DONATE TO ME
Reserved for me at the moment

Will give it a try and post here + stuff from other posts

Thanks a lot... Great idea

Sent from my HTC Flyer P510e using xda premium

EDIT:
OK just chose to install your zip in CWM - successful

Phone is rebooting... to android, not back to recovery - booting since 5 minutes
(no bootloop - HTC quietly brilliant logo visible)

EDIT2:

pressed power - powered down (vibrated once) booting again

Coolexe´s rom with your kernel just successfully started

will reboot soon to bootloeader check your stuff

EDIT3:
got into your recovery... old backups still there
Rebooted from recovery to Androd without problems now
just the first boot after installing your recovery was a hangup solved by pressing power button untill manual reboot

ALL OK

HTC Flyr 32GB 3G

DooMLoRD
Old
(Last edited by DooMLoRD; 27th December 2011 at 07:47 PM.)
#7
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
Quote:
Originally Posted by globatron View Post
DooMLoRD, can you confirm that you have off-mode charging working properly? Having a recovery that doesn't is not a good situation to get into in a device with no removable battery.
i think its charging:




i just need the recovery.img from GB (wifi/3g) & HC (3g) versions to add support for them...

porcupineadvocate
Old
#8
porcupineadvocate's Avatar
Senior Member
Thanks Meter 46
Posts: 158
Join Date: Aug 2010
I have a 3G Flyer running HC; how might one find the partition layout information you need?

Dunno if this is any help:

Code:
# mount
rootfs / rootfs ro,relatime 0 0
tmpfs /dev tmpfs rw,nosuid,relatime,mode=755 0 0
devpts /dev/pts devpts rw,relatime,mode=600 0 0
proc /proc proc rw,relatime 0 0
sysfs /sys sysfs rw,relatime 0 0
/dev/block/mmcblk0p25 /system ext4 ro,relatime,barrier=1,data=ordered 0 0
/dev/block/mmcblk0p29 /data ext4 rw,nosuid,nodev,noatime,barrier=1,nodelalloc,data=ordered 0 0
/dev/block/mmcblk0p30 /cache ext4 rw,nosuid,nodev,noatime,barrier=1,nodelalloc,data=ordered 0 0
/dev/block/mmcblk0p31 /devlog ext4 rw,nosuid,nodev,noatime,barrier=1,nodelalloc,data=ordered 0 0
none /acct cgroup rw,relatime,cpuacct 0 0
tmpfs /mnt/asec tmpfs rw,relatime,mode=755,gid=1000 0 0
tmpfs /mnt/obb tmpfs rw,relatime,mode=755,gid=1000 0 0
none /dev/cpuctl cgroup rw,relatime,cpu 0 0
/data/d /data/d debugfs rw,relatime 0 0
htcfs /data/htcfs fuse.htcfs rw,nosuid,nodev,relatime,user_id=0,group_id=0,allow_other 0 0
DxDrmServerIpc /data/DxDrm/fuse fuse.DxDrmServerIpc rw,nosuid,nodev,relatime,user_id=0,group_id=0,allow_other 0 0
/dev/block/vold/179:33 /mnt/sdcard vfat rw,dirsync,nosuid,nodev,noexec,relatime,uid=1000,gid=1015,fmask=0202,dmask=0202,
allow_utime=0020,codepage=cp437,iocharset=iso8859-1,shortname=mixed,utf8,errors=remount-ro 0 0
/dev/block/vold/179:33 /mnt/secure/asec vfat rw,dirsync,nosuid,nodev,noexec,relatime,uid=1000,gid=1015,fmask=0202,dmask=
0202,allow_utime=0020,codepage=cp437,iocharset=iso8859-1,shortname=mixed,utf8,errors=remount-ro 0 0
tmpfs /mnt/sdcard/.android_secure tmpfs ro,relatime,size=0k,mode=000 0 0
/dev/block/vold/179:65 /mnt/sdcard/ext_sd vfat rw,dirsync,nosuid,nodev,noexec,relatime,uid=1000,gid=1015,fmask=0702,dmas
k=0702,allow_utime=0020,codepage=cp437,iocharset=iso8859-1,shortname=mixed,utf8,errors=remount-ro 0 0
/dev/block/dm-0 /mnt/asec/com.robotinvader.knightmare-2 vfat ro,dirsync,nosuid,nodev,relatime,uid=1000,fmask=0222,dmask=
0222,codepage=cp437,iocharset=iso8859-1,shortname=mixed,utf8,errors=remount-ro 0 0
/dev/block/dm-1 /mnt/asec/mainwood.android.rushhourfree-1 vfat ro,dirsync,nosuid,nodev,relatime,uid=1000,fmask=0222,dmas
k=0222,codepage=cp437,iocharset=iso8859-1,shortname=mixed,utf8,errors=remount-ro 0 0
fdisk -l shows exactly nothing; /proc/mtd is empty. :S

mohamed_moscow
Old
#9
Senior Member
Thanks Meter 50
Posts: 335
Join Date: Sep 2008
Quote:
Originally Posted by DooMLoRD View Post
the necessary files for that are already in place...

may be someone can help test that...

additionally: is the partition layout on GB different? and waht abt the 3G version?
On the GB (2.23.405), 3G device it didn`t start, i got a white screen.

---------- Post added at 07:46 PM ---------- Previous post was at 07:42 PM ----------

Quote:
Originally Posted by DooMLoRD View Post
i think its charging:




i just need the recovery.img from GB (wifi/3g) & HC (3g) versions to add support for them...
Here is the recovery that works with GB (http://www.multiupload.com/0X989UZK3J )
The Following User Says Thank You to mohamed_moscow For This Useful Post: [ Click to Expand ]

DooMLoRD
Old
#10
DooMLoRD's Avatar
Recognized Developer - OP
Thanks Meter 38,225
Posts: 13,054
Join Date: Jul 2010
Location: Noida
Quote:
Originally Posted by porcupineadvocate View Post
I have a 3G Flyer running HC; how might one find the partition layout information you need?

i need the recovery.img which works for ur device...

Quote:
Originally Posted by mohamed_moscow View Post
On the GB (2.23.405), 3G device it didn`t start, i got a white screen.

---------- Post added at 07:46 PM ---------- Previous post was at 07:42 PM ----------



Here is the recovery that works with GB (http://www.multiupload.com/0X989UZK3J )
the version u quoted is for 3G GB version of flyer right?
