[KERNEL][Touchwiz/AOSP][d2tmo/d2att]~Xone Kernel Series~[02/03/2013]

djintrigue808 · 06:58 PM

[KERNEL][Touchwiz/AOSP][d2tmo/d2att]~Xone Kernel Series~[02/03/2013]

...Xone Kernel Series...

First of all I'd like to thank my buddy and teammate ptmr3. Without him this kernel would not be possible!

Xone DX is my stable kernel which is only OC up to 1674. The Xone kernel is OC up to 1950! It's now your choice to decide what you want for your phone.

This kernel is for d2tmo/d2att TW Jellybean 4.1.1 AND AOSP 4.2 ROMS!

Gtihub: https://github.com/djintrigue808

Quote:

Features:
-Linux 3.0.61
-Built with Linaro toolchain 4.7!
-OC up to 1950mhz
-Undervolted
-Added govs "Intellidemand, smartassv2, badass, lulzactive, pegasusq, abyssplug"
-Added IOSched "SIO, Zen"
-Fast and battery friendly!
-More coming soon!

Quote:

Download TW 4.1.1

Xone Kernel TW: Here...

Xone DX TW: Here...

Quote:

Download AOSP 4.2

Xone Kernel AOSP: Here...

Xone DX AOSP: Here...

Code:

Kernel Changelog:

Feb. 3:
AOSP/TW:
+Xone DX kernel; Stable and more reliable, OC up to 1674!
+More cyanogenmod merges to AOSP kernel
+Interactive governor edits
+Cleaned up some files

Feb. 1:
AOSP/TW:
+OC up to 1950mhz
+Moar UV
=See current voltage settings in post #2

Jan. 30:
AOSP/TW:
+Updated to Linux 3.0.61 (Task650)
+Row scheduler
+Pegasusq adjustments

Jan. 28:
4.2 AOSP:
+Edit min freq to 192mhz
+UV more
+Latest cyanogen kernel commits

4.1.1 TW:
+Edit min freq to 192mhz
+UV more
+Interactive governor edits
+Boot anim support enabled

Jan. 26:
4.2 AOSP:
+AOSP 4.2 Support
+Updated to Linux 3.0.60
+Add all govs and schedulers to kernel

4.1.1 TW:
+Updated kernel to Linux 3.0.60 (task650)
+block/deadline: tweaked for better performance on android (Faux)
+-O3 optos
+Modified Makefile

Jan. 24:
+Restarted with a "fresh" repo
+Updated kernel to Linux 3.0.41 (Ktoonsez)
=Built with Linaro Toolchain 4.7
+Adjustments to lulzactive governor (Ktoonsez)
+Adjustments to smartassv2 gov
+msm: Adreno 2xx GPU overclocking to 480 MHz (Faux123)
+Lulzactive rebase so its not crashing (Ktoonsez)
+cpufreq: Fix panic when setting sampling rate
+ARM: Fix deadlock scenario with smp_send_stop

Jan 23:
+Gov: Abyssplug
+Iosched: SIO
+Iosched: Zen

Jan 23:
+Initial Release

*Having trouble setting your frequencies with Xone Kernel? View here...

Quote:

Special Thanks:

Ptmr3
Deviant Development Team
Samsung
Cyanogen
Ktoonsez
task650
Morfic
Faux123
Imoseyon

djintrigue808 · 10:01 AM

Current Freq and Voltages:

{ 1, { 192000, PLL_8, 0, 2, 0x00 }, L2(1), 800000 },
{ 1, { 384000, PLL_8, 0, 2, 0x00 }, L2(1), 800000 },
{ 0, { 432000, HFPLL, 2, 0, 0x20 }, L2(7), 825000 },
{ 1, { 486000, HFPLL, 2, 0, 0x24 }, L2(7), 850000 },
{ 0, { 540000, HFPLL, 2, 0, 0x28 }, L2(7), 850000 },
{ 1, { 594000, HFPLL, 1, 0, 0x16 }, L2(7), 850000 },
{ 0, { 648000, HFPLL, 1, 0, 0x18 }, L2(7), 900000 },
{ 1, { 702000, HFPLL, 1, 0, 0x1A }, L2(7), 900000 },
{ 0, { 756000, HFPLL, 1, 0, 0x1C }, L2(7), 950000 },
{ 1, { 810000, HFPLL, 1, 0, 0x1E }, L2(7), 1000000 },
{ 0, { 864000, HFPLL, 1, 0, 0x20 }, L2(7), 1025000 },
{ 1, { 918000, HFPLL, 1, 0, 0x22 }, L2(7), 1050000 },
{ 0, { 972000, HFPLL, 1, 0, 0x24 }, L2(7), 1075000 },
{ 1, { 1026000, HFPLL, 1, 0, 0x26 }, L2(7), 1075000 },
{ 0, { 1080000, HFPLL, 1, 0, 0x28 }, L2(16), 1100000 },
{ 1, { 1134000, HFPLL, 1, 0, 0x2A }, L2(16), 1100000 },
{ 0, { 1188000, HFPLL, 1, 0, 0x2C }, L2(16), 1125000 },
{ 1, { 1242000, HFPLL, 1, 0, 0x2E }, L2(16), 1125000 },
{ 0, { 1296000, HFPLL, 1, 0, 0x30 }, L2(16), 1150000 },
{ 1, { 1350000, HFPLL, 1, 0, 0x32 }, L2(16), 1150000 },
{ 0, { 1404000, HFPLL, 1, 0, 0x34 }, L2(16), 1175000 },
{ 1, { 1458000, HFPLL, 1, 0, 0x36 }, L2(16), 1175000 },
{ 1, { 1512000, HFPLL, 1, 0, 0x38 }, L2(18), 1187500 },
{ 1, { 1674000, HFPLL, 1, 0, 0x3A }, L2(18), 1200000 },
{ 1, { 1728000, HFPLL, 1, 0, 0x3C }, L2(19), 1200000 },
{ 1, { 1809000, HFPLL, 1, 0, 0x3E }, L2(19), 1250000 },
{ 1, { 1890000, HFPLL, 1, 0, 0x40 }, L2(19), 1250000 },
{ 1, { 1950000, HFPLL, 1, 0, 0x42 }, L2(19), 1300000 },

matrixzone · 24th January 2013, 09:52 AM

Will this work for AT&T?

threshold350 · 11:55 AM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

Sweet, i will give this a try and report back if I find any issues. :thumbup:

Edit: do you have a md5?

Sent from my SGH-T999 using Tapatalk 2

RnRexpress3423 · 24th January 2013, 12:24 PM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

Fantastic! Just flashed your newest frosty rom so I will be testing this new kernel as well.

Sent from my SGH-T999 using Tapatalk 2

RotaryXperiment7 · 24th January 2013, 12:39 PM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

whats Linaro tool?

Sent from my SGH-T999 using xda premium

lmarranzino · 04:04 PM

Great work DJ and of course the Team thanks for this.... I just put in v02 waiting for it to tame....

What scheduler are you using or recommending or what is the difference between Zen and SIO still pretty new with the Kernel stuff.

Edit: Ondemand vs Smartass v2 .... Currently I have set at SAv2 with SIO battery seems to be dropping but realize it needs to settle. Other wise smooth and nice.
Using SetCpu app as well.

Again thanks

tdizzle404 · 24th January 2013, 03:45 PM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

Quote:

Originally Posted by RotaryXperiment7

whats Linaro tool?

Sent from my SGH-T999 using xda premium

A skrillex song

Sent from my SGH-T999 using xda premium

ktetreault14 · 24th January 2013, 03:55 PM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

Yes what would you recommend to use on this?

Sent from my SGH-T999 using xda premium

GalaxyS3Guy · 24th January 2013, 04:27 PM

Re: [KERNEL][TW][4.1.1]~Xone Kernel v02~[01/23/2013]

Quote:

Originally Posted by ktetreault14

Yes what would you recommend to use on this?

Sent from my SGH-T999 using xda premium

Wicked jb... Frosty jb... And domination I'm sure would all be great... Lol but I'm sure it works on all 4.1.1 tw ROMs as stated in the op

Sent from my SGH-T999 using Tapatalk 2
