[MJ9 LOCKED BL][AlPHA]SafeStrap 3.7.1-v1[i605]

24th March 2014, 07:11 PM   |  #1
Beastmode's Avatar
OP Senior Member
Flag Los Angeles
Thanks Meter: 7,374

3,783 posts
Join Date:Joined: Dec 2010
Donate to Me
More
Welcome to Safe Strap Alpha Build for the Note 2

Please Read all OP before proceeding as this is an Alpha Build

The following is Hashcode's OP just edited for our device as is Safestrap so all credit goes to Hashcode for his amazing app!

VERIZON SAMSUNG GALAXY NOTE 2 (T0LTEVZW)

*** DISCLAIMER ***
I work on projects that may brick your device. Don't sue me, hate me or try and kill my dog if that happens. I will feel bad the community will feel bad and hopefully we'll find a way to get you going again. But, the very nature of my projects involves a certain amount of risk taken by YOU. And by using the projects that I work on, you've accepted that fact.

CURRENTLY THERE IS AN UNKNOWN ISSUE WHERE IF YOU HAVE ENCRYPTION ENABLED AND INSTALL SS IT BOOTLOOPS. IF YOU FIT THIS DESCRIPTION PLEASE STAY AWAY FROM SAFESTRAP FOR NOW.


CURRENT PROJECT STATUS:
v3.71: Debugging some rom-slot issues (can't create any atm)

WHAT IS SAFESTRAP?

Safestrap is a Bootstrap / Recovery for locked bootloader phones. The goal is to avoid touching your primary system (I'll call this "stock" system) and only flash or make large changes to another place on your phone that Safestrap treats as a "2nd system" (in this case, it's a series of virtual ROM slots located on the internal emmc area: "/sdcard"). Once installed, you will see a "Splashscreen" giving you the option to hit "menu" to enter recovery. The recovery portion of Safestrap is now based on TWRP 2.7.0.0 (a touch based recovery) and you can perform .zip installs, backups and restores here. The additional features I've added to TWRP are mostly located under the "Boot Options" menu:
  1. Here you can create virtual ROM-slots (2 on the Note 2 due to partition size and internal space) for flashing ROMs. These ROM-slots allow for 3 different sizes of /data partitions: 1GB, 2GB and 3GB. NOTE: The bigger you make the /data partition the less room you will have to make other ROM-slots.
  2. You can activate a new ROM-slot by choosing the slot you wish to make active and then selecting the "Activate" button. Once active, you will see the "rom-slot#" up in the top of the screen shown in green. If you make the "stock" ROM active, then you can see it in the top shown in red.
  3. Once a ROM-slot is active, all actions you would normally perform using TWRP are directed to that ROM-slot. For example, "Install" to flash a .zip, backup and restore.

For more information you can read up here:
http://blog.hash-of-codes.com/how-to-safestrap/


HOW DO I INSTALL SAFESTRAP?
  1. Requirement: Root
  2. Requirement: Allow APK install from Unknown Sources
  3. Download the Safestrap APK
  4. Find the APK using a Filemanager tool and open it on your device, then click "Install".
  5. (If updating from an existing Safestrap you might be warned that this will over-write the existing installation. Click the "Yes" equivalent to this message.)
  6. Once installed, open up the Safestrap application as you would any other app.
  7. Agree to the disclaimer that you won't try to sue me and hunt me down with a rifle if you manage to break your phone..
  8. Then use the "Install Recovery" button. You should see the current version down in the lower left corner of the window. And the "Status:" should say "Installed" when you're done.
  9. From there you can reboot and you *should* see a new splash screen during the boot up. While this is showing you can enter Safestrap Recovery using the [ menu ] button.
  10. That's it for the installation! Read below for a brief overview of Safestrap Recovery v3.x


HOW DO I ENTER RECOVERY?

During each reboot a splashscreen will be displayed showing whether the device is running a rom-slot or on the "Stock ROM".
Press under the button shown on the screen to either enter "RECOVERY" or "CONTINUE" booting.
By "under", I mean on the touch key portion of the front display on either side of the center button.


DOWNLOADS:
CONFIRM THAT YOU ARE USING A VERIZON WIRELESS SAMSUNG GALAXY S NOTE 2

FOR USERS OF MJ9:
USE 3.71+:BETA Safestrap-t00ltevzw-3.71.apk (updated 2014-3-24)
only Mirror = SafeStrap v1

Bugs
1. Can't create Rom Slots
2, This is just an Alpha build for those who want to replace the Stock rom; must modify rom to not install boot.img because then you will have to flash back to stock.

Example of modification needed to for rom to work
Example i used the N3bula rom
1. unzip rom and go to the updater-script and aroma-config
2. compare these 2 files aroma-config and updater-script with the original files and you'll see what i removed in order to make it work.

ALSO DOWNLOAD THE KERNEL MODULES .ZIP THAT MATCHES YOUR BUILD # (FLASH THIS AFTER ROMS):
None needed at the moment.


HOW TO MANUALLY REMOVE SAFESTRAP:
[ INSTRUCTIONS ONLY FOR v3.65. REMOVE VIA APK FOR v3.70+ ]

Enter adb shell from your pc:
Code:
su
mount -o remount,rw /system
mv /system/etc/init.qcom.modem_links.sh.bin /system/etc/init.qcom.modem_links.sh
rm -rf /system/etc/safestrap
rm /system/etc/firmware/q6.mdt
ln -s /firmware/image/q6.mdt /system/etc/firmware/q6.mdt
mount -o remount,ro /system

As of version 3.7x, Safestrap Recovery is now based on TWRP 2.7.0.x. For more on TWRP you can visit their website: http://www.teamw.in/

WARNING: Safestrap is heavily modified to be "Safe" for your device. Do not download TWRP from their website and expect it to work the same way. Also TWRP does not support Safestrap, tho some issues that may come up will be TWRP dependant, please try and contact myself or look on the forums for your device for answers before hunting down TWRP people. They won't be able to help w/ Safestrap specific questions.


For the purposes of direct user testing I've established a channel on freenode.net IRC: #safestrap
I'm in the channel mostly all the time, but may not be active for discussion.

This thread is a development ONLY thread.
For discussion go here:
http://forum.xda-developers.com/show....php?t=2682577



Contributors
Hashcode, DeesTroy & TeamWin

Version Information
Current Alpha Version: 3.71
Beta Release Date: 2013-12-27

Created 2014-03-22
Last Updated 2014-03-24
Last edited by Beastmode; 24th March 2014 at 07:21 PM.
The Following 22 Users Say Thank You to Beastmode For This Useful Post: [ View ]
24th March 2014, 07:12 PM   |  #2
Beastmode's Avatar
OP Senior Member
Flag Los Angeles
Thanks Meter: 7,374

3,783 posts
Join Date:Joined: Dec 2010
Donate to Me
More
mine
The Following 2 Users Say Thank You to Beastmode For This Useful Post: [ View ]
24th March 2014, 07:14 PM   |  #3
Beastmode's Avatar
OP Senior Member
Flag Los Angeles
Thanks Meter: 7,374

3,783 posts
Join Date:Joined: Dec 2010
Donate to Me
More
FYI you can now install this app regularly like any other app instead of having to drop it into /system/app/.



enjoy
The Following 4 Users Say Thank You to Beastmode For This Useful Post: [ View ]
24th March 2014, 07:18 PM   |  #4
Senior Member
Thanks Meter: 357

537 posts
Join Date:Joined: May 2007
Donate to Me
Thumbs up
Great job.
24th March 2014, 07:33 PM   |  #5
wtoj34's Avatar
Senior Member
Flag San Antonio, TX
Thanks Meter: 150

613 posts
Join Date:Joined: Jan 2012
More
Awesome news! Excited to see this grow.

Sent from my SCH-I605 using Tapatalk
24th March 2014, 09:19 PM   |  #6
Senior Member
Thanks Meter: 52

606 posts
Join Date:Joined: Jun 2010
Thank you so much this happened perfect timing. Just got a replacement a few days ago. I love this community lol

Sent from my SCH-I605 using Tapatalk
24th March 2014, 09:31 PM   |  #7
Beastmode's Avatar
OP Senior Member
Flag Los Angeles
Thanks Meter: 7,374

3,783 posts
Join Date:Joined: Dec 2010
Donate to Me
More
Quote:
Originally Posted by HerroMoto

Thank you so much this happened perfect timing. Just got a replacement a few days ago. I love this community lol

Sent from my SCH-I605 using Tapatalk

Lol just make sure you read up its an alpha build and rom slots are not available right now you can only flash over stock rom and no kernels can be flashed.

I ♥ this community as well lol

Sent from my SCH-I605 using Tapatalk
The Following 3 Users Say Thank You to Beastmode For This Useful Post: [ View ]
25th March 2014, 02:35 AM   |  #8
laxattack's Avatar
Senior Member
Thanks Meter: 11

154 posts
Join Date:Joined: Dec 2009
More
Yay!

Sent from my SCH-I605 using Tapatalk
25th March 2014, 03:06 AM   |  #9
Member
Thanks Meter: 14

65 posts
Join Date:Joined: Mar 2014
I flashed like 3 or 4 touch wiz roms. It's safe to say all 4.3 touch wiz roms are good to go
The Following User Says Thank You to roflcoptersoisoi For This Useful Post: [ View ]
25th March 2014, 03:14 AM   |  #10
italbomber's Avatar
Senior Member
Flag New York
Thanks Meter: 141

387 posts
Join Date:Joined: Jan 2011
More
Excellent work. Will be great when it goes to official and final. Many people are stuck with these replacement phones under fort knox

Sent from my SCH-I605 using Tapatalk

The Following 2 Users Say Thank You to italbomber For This Useful Post: [ View ]
