Difference between EMUI-Recovery and Huawei eRecovery
Still uneasy about your terminology.
Screenshot-1 (attached) shows the same Recovery as in my post #477 - Recovery that I was getting with Vol+ & Pov, without USB cable, when it failed to boot to TWRP.
Screenshot-2 shows 'real' EMUI Recovery that I get with
Vol+ & Pov, also without USB cable, but now upon I flashed recovery_ramdis.img to recovery_ramdisk.
With Vol+ & Pov, and with USB cable connected to charger, it boots for me again to Screenshot-1, different from your screenshot in the post #445 (?!)
EDIT: Moved the phone with charger to another outlet (better WiFi signal), it didn't ask me for WiFi pass but it did show eRecovery as in your post #445 and started to download...
PS: eRecovery for b528 with User reset finished, About no more showing Patch01, and phone does not recognize two SIM cards - tonight will have to repeat setting the things
I've never seen your screenshot on eRecovery, but in the end, you managed to boot into eRecovery instead of EMUI Recovery and restored your phone to b528 without Patch001
To clarify it a bit more clearly (for other users and some details for you):
Start EMUI-Recovery
USB cable disconnected from phone
VOL+ and Power Button (The power button can be omitted as soon as the Huawei logo was visible - but VOL+ must be pressed until Recovery screen appear)
EMUI-Recovery has 3 options:
Reboot system now - Wipe data/factory reset - Wipe cache partition
The Start screen looks like screenshot 1
Start Huawei eRecovery
Connect phone with USB data cable to charger
Shutdown phone (It can also be done with the phone switched on, but starting from the switched off device makes it easier)
VOL+ and Power Button (same as for EMUI-Recovery power button can be omitted as soon as the Huawei logo was visible - but VOL+ must be pressed until Recovery screen appear)
Huawei eRecovery has 2 different options:
Reboot - Download latest version and recovery - Shutdown
The Start screen looks like screenshot 2
→ with eRecovery you can restore latest official Firmware for this device (even, if you want come back from AOSP Rom) - see Screenshot 3
Note: Restore with eRecovery is working, but it will wipe your data and settings
