[ROM+KERNEL][GT-N51XX]FlexBurst rom & KK_Runner kernel[DISCONTINUED]

civato · Oct 9, 2014

Samsung TouchWiz based on official KitKat rom

GT-N5100 Based on KOT49H.N5100XXDNH3

GT-N5110 Based on KOT49H.N5110XXDNI2

GT-N5110 Based on KOT49H.N5120XXDNH3

You can run this rom on JB bootloader but you will have to install a older kernel from this thread to have wifi working. I will not support it

AndroidFileHost
CivZ-DOWNLOAD CENTER

Mega
CivZ-DOWNLOAD CENTER

MD5 checksum: 217736F97F24C28E3194F2CD780B2EDC *CivZ-FlexBurst-KK_BL-Rev1.2-N5100_signed.zip

MD5 checksum: B63BC3C899EA9D76C5C4DDE534928DB0 *CivZ-FlexBurst-KK_BL-Rev1.2-N5110_signed.zip

MD5 checksum: 6214E1D62FD7687BD832FB6BEFD8A840 *CivZ-FlexBurst-KK_BL-Rev1.2-N5120_signed.zip

Aroma Features:
Menu:

Install ROM= "INSTALL FLEXNOTE ROM with root"

Install AirCommand= "REBOOT FIRST AFTER ROM INSTALLATION", Thanks to jazzespresso

Exit= "Terminate AROMA Installer",

Rom Installation:
WIDGETS & APPS selection options:

REGION CSC:

Xposed framwork & extra roo tapps

Bootanimation support

Rom Features base installation:

Miracast/Allshare cast & Google chromecast supported (see Q&A for how to)
Deodexed
Sidesync support
AirCommand possibility (Thanks to for most of the work jazzespresso)
Terminal command to enable/disable Aircommand
OG Battery or 3Minit battery mod included (see Q&A when you want stock KK battery icon)
3Minit Quicklaunch Panel @ gharrington. (position is altered so if you don't use it you just see a small "+" sign in dropdown notification)
Extra menu settings
3-way reboot
Framwork rework for the S-Pen text icon calibration
CSC hidden features enabled: Browser version info / Camera shutter sound / System Update removed / Keyboardsymbols/.......
ExternalSD Read/Write fixed
Libfiles and apps updated
KNOX removed
New CivZ KK_Runner kernel
Root SuperSU 2.13
Busybox 1.22.1
Init.d support (with the included kernel)
ViperFXSound = for updates follow this thread
Custom bootanimation support (select in aroma)
Re-Odex Script included @ MatrixDJ96 = Odex your rom after installation with a simple command = super fluid experience. See here for Instructions
Trickster mod or Synapse support (not included, download from the playstore) - preview
...

CivZ KK_RUNNER KERNEL Features

If you change nothing these are the following Features/optimisations you get compared to Stock:

Separate Kernel download link see "CivZ Download Center" (it is already included in the rom)
You want to use this kernel on a stock rom (H2 - H3 - I2 based) please flash this fix after installing the kernel or your tablet won't boot.

Miracast/Allshare cast & Google chromecast supported (see Q&A for how to)
SELINUX protection included but set at Permissive = No problems wit apps like Paragon and Titainium.
SELinux control with Synapse
S-Pen Alignment fixed + better calibration
Default Speeds 200MHz-1600MHz
Activating Saving power will result into 200MHz-1100MHz.
Init.d support
Frandom
Intelli hotplug
DynamicFSYNC Use Synapse or Trickster Mod app. = disabled by default.
mmc cap erase disabled ( just as a precaution )
Triangle away support
Optimized AES & SHA1 routines
Google Snappy compression
Memcopy & string

Driver support included in kernel:

NTFS_RW / FAT / FAT32 / EXFAT support
CIFS
Boeflla 1.6.0 Sound engine support Download Boeflla sound app from the playstore.

Advanced users support

[*]OC & UV support for CPU
[*]Max CPU speed is 1920MHz
[*]Min CPU speed is 100MHz
[*]Governors: Adaptive, Pegasusq (recommended), Performance, Ondemand, Interactive.
[*]Schedulers: cfq, Noop, Deadline, Row, Sio, VR
[*]Extra TCP wifi connection added: Westood, reno, htcp, vegas, veno.

Thanks to Andreilux - Faux123 - Yank555.lu - ZaneZam for kernel work
Thanks to jazzespresso for the Aircommand feature and rom feedback.

CHANGELOG ROM:
08/okt/2014

New Rom Rev1.1
sidesync support

30/okt/2014

New Rom Rev1.2 for the 5100 / 5110 / 5120
See Above for full details as a lot has changed as rom bases and features.

CHANGELOG KERNEL:
08/okt/2014

New Kernel Rev1.1
SideSync driver included

30/okt/2014

New Kernel Rev1.2 for the 5100 /5110 /5120
See Above for full detail.

XDA:DevDB Information
FlexBurst rom & KK_Runner kernel, ROM for the Samsung Galaxy Note 8.0

Contributors
civato
ROM OS Version: 4.4.x KitKat
ROM Kernel: Linux 3.0.x
ROM Firmware Required: KK bootloader

Version Information
Status: Stable

Created 2014-09-24
Last Updated 2015-11-15

civato · Oct 7, 2014

Q&A

Installation:
You can run this rom on JB bootloader but you will have to install a older kernel from this thread to have full wifi working. but I will not support it
First time you install KitKat rom follow the instructions. After that there is no way back to JellyBean BOOTLOADER and your warranty is void as the KNOX is tripped in bootloader. You can still install JellyBean Rom compaired with JB kernel on the new bootloader

Download the rom from this thread for your device and place it on your Note8.0
Install the latest PhilzTouch recovery for your device (I'm running philz_touch_6.41.6-n5110).
Full WIPE if you install this rom for the first time.
Install the rom and reboot

Aircommand

Bugs with Aircommand:

Chrome won't work = you need to install Chrome beta
Activating reader mode will cause a reboot when opening a app that supports reader mod

Aircommand terminal command and tips:
Remember when installing the Aircommand that you will disable some features of your note.
Like some quick command options and Spen gestures.
Why this option:
That is the reason why I build in a command that makes it possible to disable Aircommand or enable it, this way you don't need to reinstall the rom to get rid of Aircommand, with this command you only need to reboot your tablet to enable/disable it.
When you disable the Aircommand all normal features of the Note8.0 will work for 95% again. Best is to reinstall the rom.

Open terminal emulator
su (enter) airoff (enter)
su (enter) airon (enter)

Tip to pop up the Aircommand :
Go to Xblasted modules - Statusbar - Gestures and select a gesture to pop-up the Aircommand trigger app.
I did long press in statusbar. Now you can open the Aircommand in any app by long presing the statusbar area

If you are looking for the Spen window manager only (no aircommand) support I suggest you install this app (best but you need to pay for it) or this , it can only makes pen window short cuts. where the paid app allows much more options .
With one of these apps you don't need Aircommand to have the pen windows.

Stock battery or change battery icon
Use the 3minit battery app to select your favorite battery icon, the stock kk icon can be found in one of the online download sections of the app.

Kernel Q&A
Note on CIFS:
Example on what you enter, but your IP and share, if that wasn't clear. The option section is very important

Note on NTFS
You need to use Paragon!
You need to set your mount point yourself.
Example and recommended is:

Code:

 /mnt/extSdCard/paragon

Miracast/Allshare support
If it doesn't work install Triangle away from the playstore and reset your counter and select the reset at reboot.
The custom kernel support it, I tested it and I have no problems.
Black screen with miracast= ask your miracast device (TV or player) manufactor to solve it, this is not a kernel rom problem.

ramjet73 · Sep 16, 2014 at 7:43 PM

Looking forward to this new kernel.

Thanks for your ongoing support of the Note 8.0. :good:

ramjet73

tyfoxx · Sep 16, 2014 at 10:42 PM

Can't wait to flash this ROM

@BB · Sep 17, 2014 at 12:17 AM

Woo Hoo!

Thanks for this! Always great work!!

jazzespresso · Sep 17, 2014 at 1:12 AM

ramjet73 said:
Looking forward to this new kernel.

Thanks for your ongoing support of the Note 8.0. :good:

ramjet73

darn..you got first post.....heh heh heh, I was not quick heh heh heh heh

ramjet73 · Sep 17, 2014 at 1:29 AM

jazzespresso said:
darn..you got first post.....heh heh heh, I was not quick heh heh heh heh

The early bird gets the worm. Or in this case the post.

ramjet73

memooffon · Sep 17, 2014 at 3:05 AM

Will GT-N5100 continue ?

cheryanne · Sep 17, 2014 at 4:14 AM

I don't want to hound you but I just wanted to ask if you'll be adapting the kernel for the 5120. I just don't want to get my hopes up

Galaxy Note 8.0 Xposed Build N5120XXDNE4 Kernel SphereKat-Rev5.4 on Telstra LTE

k9time · Sep 17, 2014 at 5:38 AM

cheryanne said:
I don't want to hound you but I just wanted to ask if you'll be adapting the kernel for the 5120. I just don't want to get my hopes up

Galaxy Note 8.0 Xposed Build N5120XXDNE4 Kernel SphereKat-Rev5.4 on Telstra LTE

Don't blame you. It's running like butter on my 5110. But then again so have all Civato's roms.. I really hope all of you get a chance to run it..

civato · Sep 17, 2014 at 6:31 AM

memooffon said:
Will GT-N5100 continue ?

cheryanne said:
I don't want to hound you but I just wanted to ask if you'll be adapting the kernel for the 5120. I just don't want to get my hopes up

Galaxy Note 8.0 Xposed Build N5120XXDNE4 Kernel SphereKat-Rev5.4 on Telstra LTE

Yes the 5100 and 5120 will get support but as I'm building the kernel for every device separate from the official source for your device I have to do it 3 times. 5110/5100/5120.
The older kernel was all based on one source but as I want it to be bug free and smooth I want to make a clean start for every device.
Patience as I don't have much time.

Smoothness and stability is the reason why not every special feature is in the new kernel. I tested it a long time and it is compiled now in release mode. Meaning all debugging stuff is removed so the footprint is as small as possible.

I hope this answers your questions and that you are not forgotten.

ramjet73 · Sep 17, 2014

Chromecast casting!

I can confirm that Chromecast casting works with the 3.0 ROM and the Mirror Enabler app. :good:

Miracast connects to my dongle, which it didn't before, but the image doesn't appear on the remote screen. I believe that's the fault of the cheap dongle I bought but it would be great if someone with a reliable Miracast device can confirm that.

I've flashed many times since I last ran Triangle Away but didn't have to run it to get Chromecast casting working with this ROM.

ramjet73

faceN · Sep 21, 2014

Coming from Flexnote kk Rev.2.1 do I need to wipe for the new version?
Btw, thanks for your great work. I just discovered and flashed Flexnote kk last week and it is working very well ��

Edit: I am aware of your instructions to wipe if installing the ROM for the first time but I was wondering whether Rev 2.1 is considered the same ROM and is therefore updateable to the new version or not. Tx

Edit 2: OK, I might not be the smartest peg, but I think I finally got it: ~~by wiping and flashing the Rev 3 we are also flashing the recommended KK bootloader~~ which is needed to run the new kernel included in the ROM. I was wrong! We need to flash the kitkat bootloader separately through Odin. Find instructions and links to the bootloader files here and here

I did it per instructions in Q&A post and all I can say is - WOW! The wipe was totally worth it. Haven't tried all the features as I don't need them (Miracast/Allshare cast/Google chromecast, Air Commands) but all the basic stuff, S pen included, works, flies! The UI and scrolling are very fast and much smoother then in Rev 2.1 which I thought was great as it was. Embedded YouTube also works now. Your beer is on its way!

civato · Sep 17, 2014

faceN said:
Coming from Flexnote kk Rev.2.1 do I need to wipe for the new version?
Btw, thanks for your great work. I just discovered and flashed Flexnote kk last week and it is working very well ?

Edit: I am aware of your instructions to wipe if installing the ROM for the first time but I was wondering whether Rev 2.1 is considered the same ROM and is therefore updateable to the new version or not. Tx

It is possible bu don't complain if wifi or some other stuff don't work. And for this rom/kernel you need to be on KK bootloader.

ramjet73 said:
Miracast connects to my dongle, which it didn't before, but the image doesn't appear on the remote screen. I believe that's the fault of the cheap dongle I bought but it would be great if someone with a reliable Miracast device can confirm that.

ramjet73

See if it is the same with stock kernel, my guess is it will.

cheryanne · Sep 17, 2014 at 12:35 PM

civato said:
Yes the 5100 and 5120 will get support but as I'm building the kernel for every device separate from the official source for your device I have to do it 3 times. 5110/5100/5120.
The older kernel was all based on one source but as I want it to be bug free and smooth I want to make a clean start for every device.
Patience as I don't have much time.

Smoothness and stability is the reason why not every special feature is in the new kernel. I tested it a long time and it is compiled now in release mode. Meaning all debugging stuff is removed so the footprint is as small as possible.

I hope this answers your questions and that you are not forgotten.

Civato, please don't take this the wrong way but... you are my hero!

Galaxy Note 8.0 Xposed Build N5120XXDNE4 Kernel SphereKat-Rev5.4 on Telstra LTE

CCallahan · Sep 17, 2014

Thanks civato. I'm sure this is another excellent build. Will be flashing it soon. :highfive:

ramjet73 · Sep 17, 2014 at 3:35 PM

ramjet73 said:
Miracast connects to my dongle, which it didn't before, but the image doesn't appear on the remote screen. I believe that's the fault of the cheap dongle I bought but it would be great if someone with a reliable Miracast device can confirm that.

civato said:
See if it is the same with stock kernel, my guess is it will.

In previous testing with the stock ROM it would connect and then drop the connection almost immediately, which is why I think the problem is with the dongle. With this ROM it connects and stays connected but no image appears on the screen.

I'm planning to pick up this dongle once it is released. That manufacturer has support forums and frequent firmware updates so I'm hoping to have better luck with that.

ramjet73

glockman4519 · Sep 18, 2014

I am one of the many that enjoyed the plethora of battery icons to choose from in your last build so I think I'm going to stick with the last update. I followed the link in the OP and the instructions on how to obtain what i had before was a little over my head. We all appreciate your time and effort that was put into this awsome rom and kernel. Thank you again.

Sent from my GT-N5110 using XDA Premium HD app

Bibounet · Sep 18, 2014 at 1:23 AM

Civato, thanks for your best and always great work ! :angel:

Elfuente · Nov 7, 2011 133 15 0

faceN said:
Edit 2: OK, I might not be the smartest peg, but I think I finally got it: by wiping and flashing the Rev 3 we are also flashing the recommended KK bootloader which is needed to run the new kernel included in the ROM.

I was was wondering how to flash the KK bootloader? Can someone confirm or deny that this is the way to do it.
thanks a lot
