[WIP]Getting S6-Norma-N9005 Running on ATT Note 3 OC1 5.0

[carl1961]

Getting Norma-S6-N9005 Running on AT&T Samsung Galaxy Note 3 OC1 5.0(SM-N900A)​

This Threads For AT&T Note3 OC1 5.0(SM-N900A) so we help keep Note4-Norma-N9005 thread Clean ,Also help with the Fix for just AT&T.
*******************************************************************************************************************************************************************************************************​

@lijianjunyonghu Thanks for Posting for XDA the most complete note 4 port !!
Original Thread to Download Note4-Norma-N9005 Keep your EYE'S here

N900x Norma s6.zip (aroma and needs fixing for AT&T)

https://mega.co.nz/#!0dsBTSYQ!YcfIEcP83Lhxie2m2589NW7rBW0Lv-bqJ3SgeILm_jc

• You must have Root and Safestrap installed.

  Manually making N900x Norma s6.zip a SafeStrap Installable
• ATT_SafeStrap_META-INF_N900x Norma s6.zip

  Replace META-INF and Lollipop Folder with ones in zip

• Download Odin3 installable firmware for NC2 and NJ5 if you don't have them. [URL="https://mega.co.nz/#!2EE0ADaa!TBapXYrgxcESK1Hyp4HqkZI1lwGj15apdbzJonWYi9A"]N900A_NC2-NJ5_Firmware_Switch_Odin_v3.09.zip 98.1 MB[/URL]
• N900AATTDNL1_FIRMWARE.zip 48.0 MBhttps://mega.co.nz/#!fctiwLaa!_ljwhXkj-lWyRe11zdwHK6EedsQikmfJDb35q-A1gPc

UPDATE:

Thanks to @benwaffle for NC2 Flasher and figuring out how to flash kernel in Safestrap recovery

Booting safestrap and using recovery without a PC

NC2 Flasher by benwaffle
From 4.4.4 Rom's
install and give SuperSU rights, Press "Flash NC2 Kernel" kernel will install. then press OK to Reboot , or use your back arrow if your not ready to reboot. @benwaffle Latest UPDATE app is AWESOME!!

SM-N900A_N900AUCUEOC1_KERNEL_Recovery-Flashable.zip

SM-N900A_NL1_KERNEL_RecoveryFlashable.zip
Download and copy recovery installable kernel installer to sdcard, after your finished in safestrap (installing 4.4.4 rom's or add-on's Install the kernel of choice) the installer will copy boot.img to your internal sdcard and flashboot.sh will install Kernel

Using Odin and PC to install kernels

NC2-NL1-Kernel-Switch-Odin_v3.09.zip 17.8 MB
https://mega.co.nz/#!WF8wgbhS!sBP6TAvjULq1wxZn21hbzMHvWGPxH75N8ceaa20kFaw

Previous Tested Procedures Located in POST 2​

​



[carl1961]

Previous Tested Procedures

Previous Tested Procedures​

UPDATE One File Installer for AT&T Note4-Norma-N9005-Stable.zip ​

Thanks to Every One for getting things together!!​

DOWNLOAD
ATT_Note4-Norma-N9005-Stable.zip 1.89 GB
https://mega.co.nz/#!KE8FxI7Z!61GE-cA28eRy6_L7FZfYr4QDvXGJ8WPbkYxTeAKaY0I

The handwriting to (text, Form and formula) is working ok now in Snote
Thanks to @mourad75 for the fix do go here and give him Thanks!!

http://forum.xda-developers.com/showpost.php?p=58315769&postcount=3776

Fix_Handwriting_Recognition_in_S-Note_for__Norma_Note_3_4.4.4_ROM_.zip (3.78 MB)

Camera Recording Work Around
WorkAround Thanks @xxxCod3Rxxx

Use Wonder Share Power Cam

Thanks @goldmantisak

Camera 2 is quite good. Anyone wants to try, this is a link
http://www.mediafire.com/download/ojfht19brs00bnz/Camera_2_3.1.2.apk

Mirror Link
Camera_2_3.1.2.apk 9.9 MB
https://mega.co.nz/#!XEVFSYIL!sreh5TQMMFQXJ0V-tZyVwhNL2hcAfQERffhaxXxbkMs
Screen Shot

White Note4 Keyboard
VN-TEAM Keyboard Note 4 V1.1.zip

Black Note4 Keyboard

VN-TEAM Black Keyboard Note 4 V1.1.zip

Norma_Note4_Stable_Lock_Pin_and_Hot_Boot_Fix.zip 12.9 MB
https://mega.co.nz/#!aEdEnajL!0GPi0WuWi5BAEtayPKaYJXKj9yQ0wCcF5v3EUhGGK4Q

FIX for POPUP Text box input ( APN Settings, Bluetooth Settings ETC..)

ATT_Norma_Input_Fix_Framework2.jar.zip

SustemUI.apk, Removed S-find and Quick-Connect from Quick Settings

ATT_Norma_Stable_Removed_S-Find_and_Quick-Connect_SystemUI.zip (4.04 MB)

Floating Tool Box

https://play.google.com/store/apps/details?id=com.toolbox.shortcuts




[*] ATT_NJ5_Overlay-MTP-Files-to-boot-4.4.4-roms.zip. For Getting N9005 kitkat 4.4.4 beta4 Note6 boot (veiwable)
[/LIST]

CURRENT Working Progress Install Procedure ​

​

Thanks to @xxxCod3Rxxx For getting the right combination together
If your still NC2 firmware down load @Walter.White Three Files in step 3 Thanks again Walter !!
You can skip if you already have Firmware is NJ5 or Firmware NL1

• 1. Download Note4-Norma-N9005-Stable.zip
• 2. Download Note 4 Port Fix.zip
• 3. Download Fix_Airplane_AutoSignal_DJ_444_N4Port_20141225.zip
• 4. Download and install ATT_NJ5_Overlay-MTP-Files-to-boot-4.4.4-roms.zip. For Getting N9005 kitkat 4.4.4 beta4 Note6 boot (veiwable)
  [*]5. Reboot to download mode and flash the following 3 files using Odin.
  https://mega.co.nz/#!IEgT3D6b!qe1WxdnbADEo-LuWgX-ZH9eE6Wafdq15DoZoKmC2qAs & https://mega.co.nz/#!kVJwHKqA!hBNUfvDBMHthvc62ICGNcTiI-8hH0bvjPJG2-AfUsbw & https://mega.co.nz/#!ERR2AKbA!a18JYfFIXQA27aQXb57l9gjhB2LJvLMTZM0wJt0kox4
  INSTALL IN THIS ORDER
• 6. install NC2 kernel to boot SafeStrap
  [*]7. install Note4-Norma-N9005-Stable.zip
  [*]8. install Note 4 Port Fix.zip Thanks @Walter.White for moding framework2.jar
  [*]9. install Fix_Airplane_AutoSignal_DJ_444_N4Port_20141225.zip
  [*]10. install ATT_NJ5_Overlay-MTP-Files-to-boot-4.4.4-roms.zip
  [*]11. install Keyboard of your Choice color White VN-TEAM Keyboard Note 4 V1.1.zipBlack
  VN-TEAM Black Keyboard Note 4 V1.1.zip
  [*]12. install Location Fix Norma_Stable_Fix_GLocation.zip
  [*]13. install Norma_Note4_Stable_Lock_Pin_and_Hot_Boot_Fix.zip
  [*]14. install NJ5 or NL1 kernel


Goal is getting data and phone working, then we can go at it with other issues
Please post any and all issues Thanks !!

Working

• MMS
• S-Voice
• Direct Pen
• Seems Like everything except Video Recording

Location Fix Thanks to @oluwaponmile
Anyone having issue with their network location should flash the file in the link below to resolve the issue. Network location aware apps (e.g. Beautify Widgets) uses the network location API provided by Google Play Service to determine the current location even when you're indoor.

The flash will do the following:

1. Delete the NetworkLocation_Baidu.apk in /system/app
2. Set your phone to use Google network location as against baidu network location hard-coded into the framework.

Had to fix the framework to use "com.google.android.location" via the google play service API in the string.xml and in the array xml file as against "com.baidu.map.location" coded into the rom

https://mega.co.nz/#!yZ82nLyS!rA94-N0L11Yu53UeVSZaHmnDs-ySJfAOER5NZ_kngMI

Last Install Procedures Thanks @Walter.White​

@Walter.White Alright guys here is an update Flash it and report back https://mega.co.nz/#!VBQjFQYa!zxaXv9aMxt0ILh90jAQUOd_iNuk0jcWIUt3y8cFgC2w

EDIT: Right after You Install the Rom, Install the this NFCFIX.zip and then Install this ATT_Norma_Beta_Stable_Airplane_AutoSignal_HotspotTethering_Fix.zip To get data working

Also once one of you flashes the update can you please post a picture of your "Mobile Data Setting Page" (long pressing mobile data toggle will take you there directly)???

P.S. First you will have to flash NC2 kernel so that SS shows up and then once you are done flashing the rom, make sure to flash the 4.4.4 (NJ5 or NL1 kernel)[/QUOTE]

******************************************************************************************************************************************************************************************************
Older Progress Install Procedure Thanks @Walter.White​

There are still keep kinks to work out but.... Here is what you have to do!

1. Flash this original .zip (It's same as the one from last night) https://mega.co.nz/#!RZwwgLgT!ygYxfM_GERqFkdG9qF7BQ5x5Dg54bdxyi3daWuhiTw8

2. Flash this fix .zip https://mega.co.nz/#!RBZykKQa!iABs2TWRXTpe5nWO8aIRzNTanDaRkvFdDfDiWDn6s-w

3. Reboot to download mode and flash the following 3 files using Odin.
https://mega.co.nz/#!IEgT3D6b!qe1WxdnbADEo-LuWgX-ZH9eE6Wafdq15DoZoKmC2qAs & https://mega.co.nz/#!kVJwHKqA!hBNUfvDBMHthvc62ICGNcTiI-8hH0bvjPJG2-AfUsbw & https://mega.co.nz/#!ERR2AKbA!a18JYfFIXQA27aQXb57l9gjhB2LJvLMTZM0wJt0kox4

4. Now using this APN app add ATT Settings https://play.google.com/store/apps/details?id=com.SIMAPNCheck&hl=en

Name:- ATT Phone
APN :- phone
Proxy:- Not set
Port:- Not set
Username:- Not set
Password:- Not set
Server:- Not set
MMSC:- http://mmsc.mobile.att.net
MMS proxy:- proxy.mobile.att.net
MMS port:- 80
MCC:- 310
MNC:- 410
Authentication Type:- None
APN type:- default,mms,supl,hipri
APN protocol :- IPv4
Bearer:- Unspecified

---------- Post added at 09:20 PM ---------- Previous post was at 08:55 PM ----------

Anybody trying it right now?

@sapps Install Steps Thanks!! (Post 95)

Here's where I came from....about a week ago i tried to use beta 3. So i did the whole root nj5 thing. It didnt work well for me so i did the full nc2 odin restore. Since then i had been running alliance rom on full nc2.

Tonight i rebooted to SS.

1. Wipe..adv wipe...check all but external sd card. x2
2. Advanced..file manager..
a. Delete all folders on my external sd card that i didnt create... (android.secure....lost.dir...etc)
b. Navigate to data/media/0 and delete the whole folder. (Be careful with this one because you can lose SS if you delete the wrong thing.

Sidenote.....do you have to do all that, i dont know. But i know im as clean as i can get doing it that way.

3. Flash rom and then fix
4. Back out to main SS screen and hit reboot.....download
5. start odin and put all three files in their proper place.
6. Connect phone to computer and wait till it shows the com connection.
7. Press start

Phone rebooted...took about 5 minutes on boot logo the lock screen (iirc)

8. Settings....wifi...login to home wifi
9. Accounts. Put in google account.
10. Open play store and down load app linked by walter
11. It found my sim and asked if i wantes to search for apn. I said yes and choose att phone when it came up.
12. Checked the settings (they were close to what walter typed but had a few more liated in the type part)
13. Add to apn (top button not the one with root.)

All done.

SS+Boot+From+Powermenu_Recovery_Installer.zip 23.8 MB
https://mega.co.nz/#!zZsA2ApI!aqlzTctXKYOLIV3sKOy1SKnjKgUTYTOTwvy-l78uL5c



[sapps]

Awesome Carl. Thanks so much for getting this going.



[Walter.White]

@sapps @Cod3L1ne

I think we are close to getting this ROM working @carl1961 is currently testing the file I sent him. Once he reports backs we will know more



[Cod3L1ne]

@sapps @Cod3L1ne

I think we are close to getting this ROM working @carl1961 is currently testing the file I sent him. Once he reports backs we will know more

Awesome you guys are great man

Sent from my SM-G900S using Tapatalk



[Walter.White]

I'm gonna post a beta 6 zip for you guys to try it out soon.



[Walter.White]

Alright guys here it is!! @carl1961 @Cod3L1ne @sapps @tmoore3496 @mannyp01 @orphan203

Try it out and report back https://mega.co.nz/#!RZwwgLgT!ygYxfM_GERqFkdG9qF7BQ5x5Dg54bdxyi3daWuhiTw8



[orphan203]

Alright guys here it is!! @carl1961 @Cod3L1ne @sapps @tmoore3496 @mannyp01 @orphan203

Try it out and report back https://mega.co.nz/#!RZwwgLgT!ygYxfM_GERqFkdG9qF7BQ5x5Dg54bdxyi3daWuhiTw8

Walter,
Do i need to flash the overlay mtp file as well?



[Walter.White]

Walter,
Do i need to flash the overlay mtp file as well?

Nope. Just my zip



[orphan203]

Cool beans. Thanks. Loading now . Will report later this morning. Thanks.



[carl1961]

Alright guys here it is!! @carl1961 @Cod3L1ne @sapps @tmoore3496 @mannyp01 @orphan203

Try it out and report back https://mega.co.nz/#!RZwwgLgT!ygYxfM_GERqFkdG9qF7BQ5x5Dg54bdxyi3daWuhiTw8

downloading... 2 hours do you sleep zzzzzzzz LOL I'm way past my bed time



[orphan203]

Nope. Just my zip

One other thing. Will need to odin NJ5 kernal after flash correct?



[carl1961]

One other thing. Will need to odin NJ5 kernal after flash correct?

yes that is correct



[orphan203]

Carl,
How do i get data. Only CDMA is listed?

---------- Post added at 05:11 AM ---------- Previous post was at 04:54 AM ----------

@sapps @Cod3L1ne

I think we are close to getting this ROM working @carl1961 is currently testing the file I sent him. Once he reports backs we will know more

How do i acess data. Only see CDMA listed?



[Walter.White]

Carl,
How do i get data. Only CDMA is listed?

---------- Post added at 05:11 AM ---------- Previous post was at 04:54 AM ----------


How do i acess data. Only see CDMA listed?

Can you post some pics of it so I know what you mean? Also do you get 'USIM' error?



[orphan203]

Can you post some pics of it so I know what you mean? Also do you get 'USIM' error?

I did not get a USIM error



[orphan203]

My baseband is also listed as unknown. So i have no cellular service



[orphan203]

My baseband is also listed as unknown. So i have no cellular service

See attachment



[Walter.White]

I did not get a USIM error

Nice, no more 'USIM' error. It's a good start. I'll look into it tomorrow and post a fix. I need to catch some sleep.



[orphan203]

Okie dokie. Will backup and go to my normal rom.
